EM 96 51.80m Anchor Handling

General Particulars

Project Name EM 96
Basic Function Anchor Handling / Towing Tug
Classification Bureau Veritas
Descriptive Note Anchor Handling and Towing Job
Gross Tonnage 1,039 ton
L.O.A 51.80 Meters
L.B.P 44.40 Meters
Breadth Mld 15.00 Meters
Depth Mld 6.50 Meters
Design Draft 5.00 Meters
Max Draft 5.70 Meters

Towing & Anchor Handling

Bollard Pull 75~80 Ton
Hyd. Towing Winch Upper & Lower Drum Capacity 1000M x 52m Dia. Wire (10 Layers)
Brake Holding 225 Ton
Combined set Hyd. Shark Jaw / Towing Pin Shark Jaw - Maximum line tension of 300MT
Tow Pin - Maximum line tension of 200MT

Tank Capacity

Daily Fuel Oil 550.0 m3
Fresh Water 90.0 m3 with RO Plant of 5 TPD
Cargo Fuel Oil 350.0 m3

Propulsion System

2X Main Engine Mitsubitshi S12U-MPTK, 1100RPM Diesel driven with ratio 4.48:1
2X Propellers KAPLAN nozzle Type four blade fixed pitch
Steering System 2X 4.0MT Independent
Bow Thruster Unit Schottel, 7T Thrust, Diesel Engine Driven
